WIRE EROSION - SODICK AQ537L CNC Wire CUT EDM

WE OFFER AN NICE MACHINE - SODICK AQ537L    CNC Wire CUT EDM

Main technical data:

X-axis travel: 570 mm

Y-axis travel: 370 mm

Z-axis travel: 350 mm

U × V axis travel: 120 × 120 mm

Maximum workpiece dimension — flush machining: 770 × 520 × 340 mm

Maximum workpiece dimension — submerged machining: 770 × 520 × 280 mm

Maximum workpiece weight: 1,000 kg

Work tank dimensions: 1,050 × 710 mm

Taper angle at 100 mm workpiece thickness: ±25°

Wire diameter: 0.15–0.30 mm; 0.10 mm optional

Maximum wire feed speed: 420 mm/s

Wire tension: 3–23 N

Table height from floor: 995 mm

Machine dimension W × D × H: 2,600 × 2,740 × 2,390 mm

Installation space: 3,700 × 3,900 mm

Machine weight: 5,200 kg

FOR CUSTOMER WE MAKE ALSO TRANSPORT -WORLD WIDE -CUSTOMS EXPORT WORK.
